Viral filtration efficiency: |
99.99% |
|
Warranty: |
1 year |
|
Packing: |
500pcs/box |
|
Material: |
Polypropylene |
|
Size: |
6*6*6 |
|
Forward Maximum Operation Pressure: |
≥3.5bar@23℃; ≥3bar@60℃ |
|
Maximum Operating Temperature: |
60 ℃/140 ℉ |
|
Sterilization： |
By autoclave at 123℃, 30min or EO |
Materials of Construction
Filter Media:NYL/Hydrophilic PTFE/Hydrophobic PTFE/Hydrophobic PVDF/PES
(PP or GF is optional for pre-filtration layer)
Support & Drainage:PP
Sealing Technology:Thermal Welding(No Adhesives)
Dimensions
Outer Diameter
PTFE:65mm
NYL/PES/PVDF/PP/GF:60mm
Inlet/Outlet connections
7-13mm stepped hose barb connection with inner 6:100 luer slip
Filtration Area≥19.6cm2
Ratings, μm
0.1, 0.22, 0.45, 0.65
Bubble Point(PTFE 0.22 m)≥900mbar, 60%IPA
Maximum Operating Temperature:60 ℃/140 ℉
Forward Maximum Operation Pressure:≥3.5bar@23℃; ≥3bar@60℃
Sterilization：By autoclave at 123℃, 30min or EO
